Verified
1/3
Product Code: 48099.1
Mitred Shape Bolt Through Pull Handle - Grade 201 - Satin Stainless Steel
4.9 · 1954 verified reviews Verified on Trustpilot
:
Mitred Shape Bolt Through Pull Handle - Grade 201
£9.23
Mitred Shape Bolt Through Pull Handle - Grade 201
£9.23
- Free delivery over £100
- 30-day returns
- Secure checkout — Shop Pay, Klarna, Apple & Google Pay
Specifying for a project? RegAI
Speak to one of our team for advice & guidance.
RegAI
Need further information?
Contact one of the team for advice
- Call - 020 8360 7771
- Email - sales@gjohns.co.uk
Product Details
- Brushed, satin stainless steel pull handle
- High architectural quality mitred style D shape pull handle
- High grade 201 stainless steel ideal for internal doors and external entrance doors
- Suitable for use on half hour FD30 and one hour FD60 fire doors tested and passed to BS EN 1634-1 2000
- Bolt through the door design see below diagram
Above diagram shows how a bolt through pull handle is fitted to a wooden door
Alternative Fixing Options:
- Bolt through fixing with cover caps (where no finger plate is wanted on the reverse side) - see related product - 43478.
- Back to back pair (kit for fitting pull handles to both sides of the door) - see related product - 43480.
- Face fixing with roses (kit for situations where the handle cannot be fixed from the rear) - see related product - 43484.
Finish
- Satin stainless steel
Dimensions
| Item | Bolt centers (A) | Diameter (B) | Projection (C) |
|---|---|---|---|
| 48099.1 | 150mm | 19mm | 64mm |
| 48099.2 | 225mm | 19mm | 64mm |
| 48099.3 | 300mm | 19mm | 64mm |
| 48099.4 | 425mm | 19mm | 64mm |
| 48099.5 | 600mm | 19mm | 64mm |
- Free delivery on orders over £100 (£5.95 below).
- 30-day returns
Describe this product detail here.
