Eclisse Glass Sliding Pocket Door System - Double Door Kit - Supplied With Glass Doors - 125mm Finished Wall Thickness

Catalogue Number:
41118
  • Eclisse complete sliding double pocket door kit supplied with 8mm thick frosted glass doors.
  • A simple and economical way to bring more space and light into a room.
  • Ideal for use in ensuite bathrooms, kitchens, living rooms and walk-in wardrobes.
  • It's the same top quality Eclisse sliding door system coupled with two 8mm frameless glass door. The doors have a smooth, easy-clean satin opaque finish and are European made and tempered to the latest European specs.
  • Available in two door sizes off the shelf - 762mm x 1981mm or 826mm x 2040 mm and are supplied with European made glass door brackets which are tested to three times the door weight!
  • Each door is pre-fitted with a set of satin stainless steel, 58mm diameter circular handles.
Full Description Related Products
Product Name Price Qty
41118.1 - Eclisse Glass Sliding Pocket Door System - Supplied with Glass Double Doors - 125mm Finished Wall Thickness - Door Size - 762mm x 1981mm
£1,181.94 £984.95

Per Kit
Out of stock
41118.2 - Eclisse Glass Sliding Pocket Door System - Supplied with Glass Double Doors - 125mm Finished Wall Thickness - Door Size - 826mm x 2040mm
£1,210.80 £1,009.00

Per Kit
Out of stock
  • Eclisse double sliding pocket glass door kit.
  • Sliding door kit allows the two supplied 8mm thick glass interior doors to slide into a "pockets" within the wall cavity.
  • Each set includes all the main components needed to install a long lasting, smooth running, double sliding glass doors including steel wrapped studs used to create the wall cavity or "pocket" for the doors to slide into.
  • This high quality sliding glass door gear kit is suitable for residential and commercial applications. The unique design allows the 8mm glass door supplied to be installed with a finished wall of 125mm.
  • Supplied as a kit to create the pocket, which can be fully fitted in under 60 minutes by a skilled installer.
  • This is a complete pocket door kit and is supplied with two frosted 8mm thick glass doors.
  • Unlike other pocket door systems on the market the Eclisse system comes supplied complete with timber lining - jamb kits, and brush seals.

Diagram showing the wooden jamb kit supplied with the Eclisse sliding pocket door system for double doors



Supplied Complete With Glass Doors

  • 8mm thick tempered glass doors - satin opaque finish.
  • Each door is pre-fitted with a set of satin stainless steel, 58mm diameter circular handles.
  • Please note the 8mm glass doors are a satin opaque finish on one side only. If you're fitting this door inside a bathroom or shower room the satin finish side should be fitted to the dry side (not the bathroom side),



Accessories

  • 43129.1 - BIAS anti-slam soft close mechanism.



Features & Benefits

  • Space saving - sliding doors help create up to 8% more living more space within a property
  • Easy access
  • Quiet operation
  • Easy installation
  • Economical
  • Prefabricated components

Dimensions - Frame Sizes & Door Kit Sizes Available

Diagram showing dimensions of the Eclisse sliding pocket door gear system for double doors

Item Code Door Size - Each Door (DW x DH) Max Passage Size (PW x PH) Overall Frame Size (W x H) Finished Wall Thickness
41118.1 762mm x 1981mm 1474mm x 1971mm 3168mm x 2061mm 125mm*
41118.2 826mm x 2040mm  1600mm x 2030mm 3294mm x 2120mm 125mm*
  • * Double door kit to suit a 100mm finished wall thickness also available.
  • Please note plasterboard is not provided with this kit and must be bought separately.


Items Included Within The Eclisse Glass Pocket Sliding Door Kit

  • 2 x 8mm thick glass doors - frosted / opaque satin finish - plain design,
  • Metal frame work to create the "pocket"
  • Screws to fix plasterboard to metal frame - (Plasterboard not supplied)
  • Roller bearing door hanger kit
  • Timber lining kit - (door jamb kit) including brush seals and rubber bumpers.



Installation Video

Eclisse Jamb Kit - Installation Video

More Information
Item 41118
Item Code 41118
Finish -
Dimensions 150mm Wall Thickness
Sold Per Kit
Availability Non stock product - sent direct from factory - please allow 1-2 working days for delivery
Non stock product - sent direct from factory - please allow 1-2 working days for delivery
Download PDF Data Sheet
